Comet CAA-500 Mark II Antenna Analyzer 1.8-500MHz SWR Sweep Ham Radio
This unit requires 6x AA alkaline or NiMH batteries (stored in the compartment on the rear of the unit). A DC external power cable is included for external power supply use. NiMH rechargeable batteries can be charged inside the unit by connecting an external power supply. Standard alkaline batteries (including alkaline) cannot be charged - do not attempt to charge them using this function. Comet CAA-500 Mark II Antenna Analyzer.
The Comet CAA-500 Mark II is an advanced antenna analyzer covering 1.8-500 MHz across 35 range divisions, designed for amateur radio operators who need accurate SWR and impedance measurements. Building on the popular CAA-500, the Mark II adds a color LCD display, one-button SWR frequency sweep, built-in NiMH charging, and auto power-off for enhanced usability in the field. 1.8-inch color LCD displays frequency, SWR, impedance, and battery level graphically. SWR frequency sweep: one button automatically sweeps near the measured frequency and plots the SWR waveform.
Manual plot mode also available for SWR sweep. Built-in NiMH battery charging - simply connect external power with batteries installed. Auto power-off function: configurable from 1 to 9 minutes (1-minute increments). Dual connectors with automatic switching: M-J for HF/VHF, N-J for UHF.Both mechanical meter and LCD readout for SWR and impedance. Frequency Range: 1.8-500 MHz, 35 range divisions. RF Output Level: HF/VHF 0 dBm (1 mW); UHF -1 dBm approx. SWR Range: Mechanical 1.0-6.0 / LCD 1.0-9.9. , no polarity (1.8-190 MHz band).
Power: 6x AA alkaline or NiMH batteries. External Power: DC 8-16 V (center pin positive). Current Consumption: 190 mA or less. 15 hours (DC 12-14 V).Dimensions: W89 × H180(196) × D61(67) mm / W3.5 × H7.1(7.7) × D2.4(2.6) in (figures in parentheses include protrusions). 820 g (28.9 oz) body only; approx. 960 g (33.9 oz) with batteries. What's in the Box. CAA-500 Mark II Antenna Analyzer (main unit).
DC cable with external power plug (white wire = positive). We handle with only 100% authentic high-quality items that procure from Japanese reliable partner companies.
