Diamond Antenna K9000 Motor Drive Mount Daiichi Denpa Kogyo

International Buyers - Please Note. Are sent DDP (Delivered Duty Paid).

You can choose from five types of mounting hardware to suit the base and the installation location. No troublesome wiring is required, and you can use it immediately by plugging it into the cigarette lighter socket.

You can freely adjust the angle of the antenna within the range of 45 to 90 degrees, so the antenna will not hit any obstacles such as spoilers. The LED lamp indicates the direction in which the antenna will fold. There is no rattling, and the strength of the antenna support is excellent. External dimensions: W64 x H66 x D102.

Weight: 440g (motorized base unit only). Operating voltage: DC13.8V (1016V). Current consumption: 0.95Amax (13.8V). Operating angle: 4590 degrees adjustable. Maximum antenna length: 1.4m or less, weight: 350g or less. The main unit (K9000) cannot be used on its own. A dedicated metal fitting is required separately. Compatible with trunks and hatchbacks measuring 5.5mm or less. Compatible with roof sides measuring 25mm or less.

Compatible with roof rails (pipes) measuring 50mm or less in length and 48mm or less in width. 34, roof rail of height 32mm or less and width 50mm or less, square pipe of 15 to 26mm or less on one side.

---
