BOOMERANG PRO DMR DUPLEX HOTSPOT. This unit comes with our default configuration which provides an excellent starting point and minimizes the steps needed to get the unit up and running.

Follow our user manual (see link below) to quickly configure the unit. Power adapter (5V USB / 110-220VAC / 3 to 4 Amp - do not used other power adapters with lower current). Frequency range: 144MHz - 148MHz / 420MHz - 475MHz (stay away from the edges by at least 1 MHz). Bands: VHF / UHF (best used on UHF preconfigured frequencies 434/439MHz). Supported systems: DMR, YSF, C4FM, P25, NXDN, DSTAR, POCSAG.

Time slot monitoring: Both T1 and T2. Processor: Raspberry Pi4 (or PI 3 B+ depending on availability - both perform well). Power: USB power adapter included. RJ45 Ethernet port for LAN connectivity. WiFi capable for wireless connectivity. 1.3 large LCD screen (white on black for better visibility). 2 Antennas (TX/RX) with 2 - 3di gain.

Size: About 2.5" x 3.5" x 1. PDF manual and setup instructions.

The picture may not be 100% representative of the unit that you will receive since we are continuously making updates and changes to this device. We also have a couple of variations of this product depending on parts availability. Please use the power adapter provided with the unit as it outputs the needed power (5V 2.5 - 3A min).
