DMR Hotspot Duplex MMDVM TS1 & TS2 UHF Display Ethernet WIFI Boomerang ULTRA

BOOMERANG ULTRA DMR DUPLEX HOTSPOT. This Boomerang hotspot comes with our CQRADIOS default hotspot configuration which provides an excellent starting point and minimizes the steps needed to get the unit up and running. Follow our user manual (see link below) to quickly configure the unit. Power adapter (5V USB / 110-220VAC / 3 to 4 Amp - do not used other power adapters with lower current).

Frequency range: 144MHz - 148MHz / 420MHz - 475MHz (stay away from the edges by at least 1 MHz). Bands: VHF / UHF (best used on UHF preconfigured frequencies 434/439MHz). Supported systems: DMR, YSF, C4FM, P25, NXDN, DSTAR, POCSAG. Time slot monitoring: Both T1 and T2. Processor: Raspberry Pi 0 2W (or W depending on availability - both perform well with this unit).

Power: USB power adapter included. RJ45 Ethernet port for LAN connectivity.

WiFi capable for wireless connectivity. 1.3 large LCD screen (white on black for better visibility). 2 Antennas (TX/RX) with 2 - 3di gain.

Size: About 2.5" x 3.5" x 1. PDF manual and setup instructions. The picture may not be 100% representative of the unit that you will receive since we are continuously making updates and changes to this device. We also have a couple of variations of this product depending on parts availability. Please use the power adapter provided with the unit as it outputs the needed power (5V 2.5 - 3A min).

The ULTRA looks like the PRO. The difference between our hotspots. The PRO: is the most powerful and works best at home or office. Requires 3.5A at 5VDC.

The Mini: is a light weight hotspot requiring low power and is best suited for your car, on the go, or at home. The ULTRA: this unit is between the PRO and the Mini.

It works well at home with it's Ethernet connection but also has a low power consumption making well suited for the road. The Nano: This is a battery powered unit and is best used on the go close to the radio.

If you are not sure, the ULTRA will be the one!

---
